Class notification

• DNV +1A1 HSLC R2 PATROL

Overview

• Trading area: World wide
• Complement total: 12 pax + crew
• Hull: Aluminium
• Displacement (light ship): not official
• Length o. a.: 21,25 m
• Breadth: 7,66 m
• Draft: 1,3 m
• Air draft: 8 m
• Bunker capacity, diesel oil: 5000 liters
• Fresh water capacity: 400 liters
• Total forward deck capacity: 54 m2
• Forward deck dimensions: 9,75 m X 7,66 m

Cargo handling

• Max cargo capacity on deck: TBA
• Maker: Palfinger
• Model: PC2300
• Max lifting capacity @ max outreach: 1820 kg @ 1,2 m

Main and auxilary machinery

• Main engines: Catepillar Acert 32
• Power: 1081 bkW @ 2100 rpm
• Propulsion type: Fixed pitch propellers
• Propulsion equipment: Helseth 4-blade
• Auxiliary engine: Perkins/Stamford
• Output: 22,5 kW / 50 Hz
• Bowthruster: Petter Marine Hydraulics 50 hk
• Speed max: 35 knots
• Speed service: 30 knots
• Bunker consumption: TBA liters/h (service speed)
• Bunker consumption: TBA liters/h (max speed)

Navigation and communication equipment

• Radar: Furuno FAR-2117BB, FR-8065
• El. chart system: Furuno ECDIS FMD-3100 – 24”
• AIS:VDL 6000-42-xx – VDL 6000 AIS
• Heading system: Furuno Satellite Compass SC-50
• GPS/DGPS: Furuno GP-170
• Autopilot: Simrad AP-70
• Depth sounder: Furuno FCV-627
• Navtex: Furuno NX-700B
• E-mail: TBA
